Description
*Pictured in Aluminum* – All current models will be built with Aluminum composite panels 2mm thick with choice of 15 plus colors – Diamond tread front and rear corners – Diamond tread fenders – 3” Bottom trim!
8.5 x 36 Triple Axle Auto Carrier
Included Features:
- 2 Foot Rounded Front V-nose (in addition to the 36 foot box = 38 Foot)
- 2×8 Tubular Steel Main Frame (No I-Beam)
- Triple Tube front Tongue
- Silver Exterior Aluminum Composite Panels 2mm
- Diamond tread front and rear corners
- Diamond tread fenders
- 3” Bottom trim
- Screwed Exterior
- 12″ on center floor cross members
- Tubular 12″ on center wall studs
- Tubular 12″ On center roof
- Super Heavy Duty 2 5/16th Front Adjustable Coupler
- 7000# Tongue Jack
- 3/4″ plywood floor
- 3/8″ plywood walls
- 4500 lb Ramp with 16″ Steel flap extension
- 48″ R/V Style Side Door
- 16″ Silver Mod Wheels with 235/80/16 Radial Tires
- (8) Floor D-rings – recessed and bolted in place with steel plate
- (4) interior 12 volt dome light – All lights roof mounted and wired to a wall switch
- All LED lights
- Aluminum side wall vents
- Non-powered roof vent
- 6 foot 6 inch interior height
- 24″ Diamond Tread Stoneguard
- Black Undercoating
- Corrugated Galvanized Mesa roof
- Three dropped 7000 lb Leaf spring axles
- Electric Brakes (all 3 axles)
- Easy Lube Hubs
- DOT Reflective Tape
- Sand foot on tongue jack
- Deluxe tag bracket
